VELA maintenance free battery widely used for solar system
Place of Origin:
China
Brand Name:
VELA &PERSEUS
Price:
Negotiate
Packing Details:
cartons &pallet,or depend on customer
Delivery time:
about 30 days
Payment terms:
L/C,T/T
Enterprise Strength
- Customers' needs are the foundation for VELA Industrial Battery to achieve long-term development. In order to better serve customers and further meet their needs, we run a comprehensive after-sales service system to solve their problems. We sincerely and patiently provide services including information consultation, technical training, and product maintenance and so on.
Application Scope
As one of VELA Industrial Battery's main products, motorcycle batteries has wide applications. It is mainly used in the following aspects.VELA Industrial Battery is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.
1. As for the design of VELA solar battery , it always uses the updated design concept and follows the ongoing trend, thus it is extremely attractive in its appearance.
2. With the capacity to bear long time use, the product is highly durable.
3. This product is ensured by our QC team who conducts a stringent quality check process.
4. The product has a wide application and a great market value.
product description
Gel batteries use gel electrolytes, reducing the risk of spillage and evaporation due to corrosion. Due to the gelled solution can hold their charge for a longer time, so the gel battery have a longer service life than the traditional battery. And it can withstand extreme ranges in temperature. Nowadays it widely used in water pumping, solar system, UPS system, golf cars etc.
Features
Best suited for Deep cycle applications
Maintenance free
vibration-resistant
Lowest cost-per-month
Lowest cost-per-cycle
Good low temperature performance
Good recovery in deep discharge characteristics
Completely leak-proof and splash-proof, easy to install in almost any position
Maintenance free
vibration-resistant
Lowest cost-per-month
Lowest cost-per-cycle
Good low temperature performance
Good recovery in deep discharge characteristics
Completely leak-proof and splash-proof, easy to install in almost any position
Application
UPS system
Solar and wind systems
Marine Equipment
Medical Equipment
Military Equipment
Emergency lighting
Commercial deep cycle applications
Power plant
Telecommunications
Golf cars
Wheelchair
Water pumping
Solar and wind systems
Marine Equipment
Medical Equipment
Military Equipment
Emergency lighting
Commercial deep cycle applications
Power plant
Telecommunications
Golf cars
Wheelchair
Water pumping
General Technical Specifications
| Model | Nominal Voltage (V) | Capacity (AH) | Internal Resistance (mOhm) | Dimensions（mm/in） | Terminal | Weight ±4%(Kg) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | Width | Height | Total Height | ||||||||||||
| mm | in | mm | in | mm | in | mm | in | Type | Position | Kg | Lbs | ||||
| FPG12180 | 12 | 18 | 16 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | T8 | C | 5 | 11.02 |
| FPG12240 | 12 | 24 | 20 | 166 | 6.54 | 175 | 6.89 | 125 | 4.92 | 125 | 4.92 | T8 | C | 7.4 | 16.31 |
| FPG12280 | 12 | 28 | 15 | 8 | 17.64 | ||||||||||
| FPG12280A | 12 | 28 | 14 | 165 | 6.5 | 125 | 4.92 | 175 | 6.89 | 175 | 6.89 | T8 | C | 9 | 19.84 |
| LFPG6100 | 6 | 100 | 3.3 | 194 | 7.6 | 170 | 6.7 | 205 | 8.1 | 205 | 8.1 | T9 | A | 15.8 | 34.83 |
| LFPG6190 | 6 | 190 | 2.2 | 243 | 9.6 | 187 | 7.4 | 253 | 10 | 276 | 10.9 | T11 | A | 31 | 68.34 |
| LFPG1233 | 12 | 33 | 11 | 195 | 7.7 | 130 | 5.1 | 155 | 8.9 | 155 | 8.9 | T9 | C | 10.2 | 22.49 |
| LFPG1240 | 12 | 40 | 9.5 | 197 | 7.8 | 165 | 6.5 | 170 | 6.7 | 170 | 6.7 | T9 | D | 12.5 | 27.56 |
| LFPG1255 | 12 | 55 | 7 | 229 | 9 | 138 | 5.4 | 208 | 8.2 | 208 | 8.2 | T9 | C | 17 | 37.48 |
| LFPG1265 | 12 | 65 | 6.6 | 350 | 3.8 | 167 | 6.6 | 179 | 7 | 179 | 7 | T9 | C | 21 | 46.30 |
| LFPG1260 | 12 | 60 | 7.7 | 22 | 48.50 | ||||||||||
| LFPG1270 | 12 | 70 | 7 | 260 | 10.2 | 168 | 6.6 | 211 | 8.3 | 211 | 8.3 | T9 | C | 24 | 52.91 |
| LFPG1280 | 12 | 80 | 6.5 | 306 | 12.05 | 169 | 6.65 | 211 | 8.3 | 211 | 8.3 | T9 | C | 27.5 | 60.63 |
| LFPG1290 | 12 | 90 | 5.8 | 306 | 12.05 | 169 | 6.65 | 211 | 8.3 | 211 | 8.3 | T9 | C | 28.5 | 62.83 |
| LFPG1290H | 12 | 90 | 5.4 | 330 | 13 | 171 | 6.7 | 214 | 8.4 | 214 | 8.4 | T9 | C | 31 | 68.34 |
| LFPG12100 | 12 | 100 | 5 | 330 | 13 | 171 | 6.7 | 214 | 8.4 | 214 | 8.4 | T9 | C | 32 | 70.55 |
| LFPG12110 | 12 | 110 | 5.2 | 330 | 13 | 171 | 6.7 | 225 | 8.86 | 225 | 8.86 | T9 | C | 33.5 | 73.85 |
| LFPG12120 | 12 | 120 | 4.4 | 409 | 16.1 | 176 | 6.9 | 225 | 8.9 | 225 | 8.9 | T11 | C | 36.5 | 80.47 |
| LFPG12140 | 12 | 134 | 4.2 | 342 | 13.5 | 172 | 6.8 | 280 | 11 | 280 | 11 | T11 | C | 42.5 | 93.70 |
| LFPG12150 | 12 | 150 | 3.9 | 485 | 19.1 | 172 | 6.8 | 240 | 9.4 | 240 | 9.4 | T11 | C | 44 | 97.00 |
| LFPG12180 | 12 | 180 | 3.6 | 494 | 19.4 | 206 | 8.1 | 209 | 8.2 | 209 | 8.2 | T11 | C | 55 | 121.25 |
| LFPG12160 | 12 | 160 | 3.2 | 530 | 20.8 | 207 | 8.15 | 214 | 8.43 | 214 | 8.43 | T11 | C | 53 | 116.84 |
| LFPG12200 | 12 | 200 | 3.3 | 522 | 20.6 | 238 | 9.4 | 218 | 8.6 | 218 | 8.6 | T11 | C | 66 | 145.51 |
| LFPG12250 | 12 | 250 | 2.9 | 521 | 20.5 | 269 | 10.6 | 220 | 8.7 | 220 | 8.7 | T11 | E | 75 | 165.35 |
| LFPG1250FT | 12 | 50 | 7.2 | 277 | 10.91 | 106 | 4.17 | 221 | 8.7 | 221 | 8.7 | T9 | E | 17 | 37.48 |
| LFPG12100FT | 12 | 100 | 5.4 | 506 | 19.9 | 110 | 4.3 | 224 | 8.8 | 239 | 9.4 | T9 | E | 31 | 68.34 |
| LFPG12150FT | 12 | 150 | 4 | 551 | 21.7 | 110 | 4.3 | 287 | 11.3 | 287 | 11.3 | T11 | E | 47 | 103.62 |
| LFPG12180FT | 12 | 180 | 3 | 546 | 21.5 | 125 | 4.9 | 317 | 12.5 | 323 | 12.7 | T11 | E | 57 | 125.66 |
| CFPG2100 | 2 | 100 | 0.9 | 171 | 6.7 | 72 | 2.8 | 206 | 8.1 | 209 | 8.2 | T10 | A | 6 | 13.23 |
| CFPG2150 | 2 | 150 | 0.7 | 171 | 6.7 | 102 | 4 | 206 | 8.1 | 211 | 8.3 | T10 | A | 8.5 | 18.74 |
| CFPG2200 | 2 | 200 | 0.95 | 173 | 6.8 | 109 | 4.3 | 330 | 8.3 | 364 | 14.3 | T10 | G | 14 | 30.86 |
| CFPG2300 | 2 | 300 | 0.8 | 171 | 6.7 | 151 | 5.9 | 330 | 8.3 | 364 | 14.3 | T10 | G | 19.5 | 42.99 |
| CFPG2400 | 2 | 400 | 0.65 | 210 | 8.3 | 176 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | H | 26.5 | 58.42 |
| CFPG2500 | 2 | 500 | 0.55 | 241 | 9.5 | 171 | 6.7 | 330 | 8.3 | 365 | 14.4 | T10 | H | 31.5 | 69.45 |
| CFPG2600 | 2 | 600 | 0.5 | 302 | 11.9 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | H | 38 | 83.78 |
| CFPG2800 | 2 | 800 | 0.4 | 410 | 16.1 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | I | 53.5 | 117.95 |
| CFPG21000 | 2 | 1000 | 0.3 | 475 | 18.7 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | I | 64 | 141.10 |
| CFPG21500 | 2 | 1500 | 0.22 | 400 | 15.7 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | J | 97 | 213.85 |
| CFPG22000 | 2 | 2000 | 0.2 | 490 | 19.3 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | K | 130 | 286.60 |
| CFPG23000 | 2 | 3000 | 0.13 | 710 | 28 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | K | 198 | 436.52 |
| CFPG2200S | 2 | 200 | 0.9 | 206 | 8.1 | 103 | 4.1 | 355 | 14 | 390 | 15.4 | T10 | G | 15.5 | 34.17 |
| CFPG2250S | 2 | 250 | 0.8 | 206 | 8.1 | 124 | 4.9 | 355 | 14 | 390 | 15.4 | T10 | G | 19 | 41.89 |
| CFPG2300S | 2 | 300 | 0.75 | 206 | 8.1 | 145 | 5.7 | 355 | 14 | 390 | 15.4 | T10 | G | 21 | 46.30 |
| CFPG2350S | 2 | 350 | 0.7 | 206 | 8.1 | 124 | 4.9 | 471 | 18.5 | 506 | 19.9 | T10 | G | 24 | 52.91 |
| CFPG2400S | 2 | 400 | 0.6 | 206 | 8.1 | 145 | 5.7 | 471 | 18.5 | 506 | 19.9 | T10 | G | 27.5 | 60.63 |
| CFPG2500S | 2 | 500 | 0.5 | 206 | 8.1 | 166 | 6.5 | 471 | 18.5 | 506 | 19.9 | T10 | G | 32 | 70.55 |
| CFPG2600S | 2 | 600 | 0.45 | 206 | 8.1 | 145 | 5.7 | 646 | 25.4 | 681 | 26.8 | T10 | G | 43 | 94.80 |
| CFPG2800S | 2 | 800 | 0.4 | 210 | 8.3 | 191 | 7.5 | 646 | 25.4 | 681 | 26.8 | T10 | H | 60 | 132.28 |
| CFPG21000S | 2 | 1000 | 0.33 | 233 | 9.2 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 | H | 71 | 156.53 |
| CFPG21200S | 2 | 1200 | 0.28 | 275 | 10.8 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 | H | 87 | 191.80 |
| CFPG21500S | 2 | 1500 | 0.22 | 275 | 10.8 | 210 | 8.3 | 796 | 31.3 | 831 | 26.8 | T10 | H | 105 | 231.49 |
| CFPG22000S | 2 | 2000 | 0.2 | 399 | 15.7 | 210 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 150 | 330.69 |
| CFPG22500S | 2 | 2500 | 0.17 | 487 | 19.2 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 187 | 412.26 |
| CFPG23000S | 2 | 3000 | 0.13 | 576 | 22.7 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 223 | 491.63 |
Company Features
1. VELA Power Technology Co., Ltd. has been deemed as one of the prestigious establishments in the solar battery manufacturing business in China.
2. We boast our dedicated design and manufacture team. They are a must to ensure the operation of our company and are the major reason why clients turn to us for all their manufacturing needs.
3. VELA Power Technology Co., Ltd. persists in the service theory of deep cycle solar batteries . Inquiry! Relying on thousands of R&D teams, VELA Power Technology Co., Ltd. is committed to deep cycle battery . Inquiry! VELA Power Technology Co., Ltd. insists that quality is more important than productivity. Inquiry! VELA Power Technology Co., Ltd. takes honesty as the most important quality during business cooperation. Inquiry!
