durable industry batteries best for telecommunications system
Place of Origin:
China
Brand Name:
VELA &PERSEUS
Price:
Negotiate
Packing Details:
cartons &pallet,or depend on customer
Delivery time:
about 30 days
Payment terms:
L/C,T/T
Application Scope
VELA Industrial Battery's motorcycle batteries can be used in multiple industries.In addition to providing high-quality products, VELA Industrial Battery also provides effective solutions based on the actual conditions and the needs of different customers.
1. The commercial test results of industry batteries indicated that this product is characterized by deep cycle battery .
2. With its great advantages of deep cycle battery , industry batteries has been widely applied in the fields.
3. industry batteries make a feature of deep cycle battery .
4. VELA Power Technology Co., Ltd. is constantly on the lookout for opportunities to improve its customer service.
product description
Gel batteries use gel electrolytes, reducing the risk of spillage and evaporation due to corrosion. Due to the gelled solution can hold their charge for a longer time, so the gel battery have a longer service life than the traditional battery. And it can withstand extreme ranges in temperature. Nowadays it widely used in water pumping, solar system, UPS system, golf cars etc.
Features
Best suited for Deep cycle applications
Maintenance free
vibration-resistant
Lowest cost-per-month
Lowest cost-per-cycle
Good low temperature performance
Good recovery in deep discharge characteristics
Completely leak-proof and splash-proof, easy to install in almost any position
Maintenance free
vibration-resistant
Lowest cost-per-month
Lowest cost-per-cycle
Good low temperature performance
Good recovery in deep discharge characteristics
Completely leak-proof and splash-proof, easy to install in almost any position
Application
UPS system
Solar and wind systems
Marine Equipment
Medical Equipment
Military Equipment
Emergency lighting
Commercial deep cycle applications
Power plant
Telecommunications
Golf cars
Wheelchair
Water pumping
Solar and wind systems
Marine Equipment
Medical Equipment
Military Equipment
Emergency lighting
Commercial deep cycle applications
Power plant
Telecommunications
Golf cars
Wheelchair
Water pumping
General Technical Specifications
| Model | Nominal Voltage (V) | Capacity (AH) | Internal Resistance (mOhm) | Dimensions（mm/in） | Terminal | Weight ±4%(Kg) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | Width | Height | Total Height | ||||||||||||
| mm | in | mm | in | mm | in | mm | in | Type | Position | Kg | Lbs | ||||
| FPG12180 | 12 | 18 | 16 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | T8 | C | 5 | 11.02 |
| FPG12240 | 12 | 24 | 20 | 166 | 6.54 | 175 | 6.89 | 125 | 4.92 | 125 | 4.92 | T8 | C | 7.4 | 16.31 |
| FPG12280 | 12 | 28 | 15 | 8 | 17.64 | ||||||||||
| FPG12280A | 12 | 28 | 14 | 165 | 6.5 | 125 | 4.92 | 175 | 6.89 | 175 | 6.89 | T8 | C | 9 | 19.84 |
| LFPG6100 | 6 | 100 | 3.3 | 194 | 7.6 | 170 | 6.7 | 205 | 8.1 | 205 | 8.1 | T9 | A | 15.8 | 34.83 |
| LFPG6190 | 6 | 190 | 2.2 | 243 | 9.6 | 187 | 7.4 | 253 | 10 | 276 | 10.9 | T11 | A | 31 | 68.34 |
| LFPG1233 | 12 | 33 | 11 | 195 | 7.7 | 130 | 5.1 | 155 | 8.9 | 155 | 8.9 | T9 | C | 10.2 | 22.49 |
| LFPG1240 | 12 | 40 | 9.5 | 197 | 7.8 | 165 | 6.5 | 170 | 6.7 | 170 | 6.7 | T9 | D | 12.5 | 27.56 |
| LFPG1255 | 12 | 55 | 7 | 229 | 9 | 138 | 5.4 | 208 | 8.2 | 208 | 8.2 | T9 | C | 17 | 37.48 |
| LFPG1265 | 12 | 65 | 6.6 | 350 | 3.8 | 167 | 6.6 | 179 | 7 | 179 | 7 | T9 | C | 21 | 46.30 |
| LFPG1260 | 12 | 60 | 7.7 | 22 | 48.50 | ||||||||||
| LFPG1270 | 12 | 70 | 7 | 260 | 10.2 | 168 | 6.6 | 211 | 8.3 | 211 | 8.3 | T9 | C | 24 | 52.91 |
| LFPG1280 | 12 | 80 | 6.5 | 306 | 12.05 | 169 | 6.65 | 211 | 8.3 | 211 | 8.3 | T9 | C | 27.5 | 60.63 |
| LFPG1290 | 12 | 90 | 5.8 | 306 | 12.05 | 169 | 6.65 | 211 | 8.3 | 211 | 8.3 | T9 | C | 28.5 | 62.83 |
| LFPG1290H | 12 | 90 | 5.4 | 330 | 13 | 171 | 6.7 | 214 | 8.4 | 214 | 8.4 | T9 | C | 31 | 68.34 |
| LFPG12100 | 12 | 100 | 5 | 330 | 13 | 171 | 6.7 | 214 | 8.4 | 214 | 8.4 | T9 | C | 32 | 70.55 |
| LFPG12110 | 12 | 110 | 5.2 | 330 | 13 | 171 | 6.7 | 225 | 8.86 | 225 | 8.86 | T9 | C | 33.5 | 73.85 |
| LFPG12120 | 12 | 120 | 4.4 | 409 | 16.1 | 176 | 6.9 | 225 | 8.9 | 225 | 8.9 | T11 | C | 36.5 | 80.47 |
| LFPG12140 | 12 | 134 | 4.2 | 342 | 13.5 | 172 | 6.8 | 280 | 11 | 280 | 11 | T11 | C | 42.5 | 93.70 |
| LFPG12150 | 12 | 150 | 3.9 | 485 | 19.1 | 172 | 6.8 | 240 | 9.4 | 240 | 9.4 | T11 | C | 44 | 97.00 |
| LFPG12180 | 12 | 180 | 3.6 | 494 | 19.4 | 206 | 8.1 | 209 | 8.2 | 209 | 8.2 | T11 | C | 55 | 121.25 |
| LFPG12160 | 12 | 160 | 3.2 | 530 | 20.8 | 207 | 8.15 | 214 | 8.43 | 214 | 8.43 | T11 | C | 53 | 116.84 |
| LFPG12200 | 12 | 200 | 3.3 | 522 | 20.6 | 238 | 9.4 | 218 | 8.6 | 218 | 8.6 | T11 | C | 66 | 145.51 |
| LFPG12250 | 12 | 250 | 2.9 | 521 | 20.5 | 269 | 10.6 | 220 | 8.7 | 220 | 8.7 | T11 | E | 75 | 165.35 |
| LFPG1250FT | 12 | 50 | 7.2 | 277 | 10.91 | 106 | 4.17 | 221 | 8.7 | 221 | 8.7 | T9 | E | 17 | 37.48 |
| LFPG12100FT | 12 | 100 | 5.4 | 506 | 19.9 | 110 | 4.3 | 224 | 8.8 | 239 | 9.4 | T9 | E | 31 | 68.34 |
| LFPG12150FT | 12 | 150 | 4 | 551 | 21.7 | 110 | 4.3 | 287 | 11.3 | 287 | 11.3 | T11 | E | 47 | 103.62 |
| LFPG12180FT | 12 | 180 | 3 | 546 | 21.5 | 125 | 4.9 | 317 | 12.5 | 323 | 12.7 | T11 | E | 57 | 125.66 |
| CFPG2100 | 2 | 100 | 0.9 | 171 | 6.7 | 72 | 2.8 | 206 | 8.1 | 209 | 8.2 | T10 | A | 6 | 13.23 |
| CFPG2150 | 2 | 150 | 0.7 | 171 | 6.7 | 102 | 4 | 206 | 8.1 | 211 | 8.3 | T10 | A | 8.5 | 18.74 |
| CFPG2200 | 2 | 200 | 0.95 | 173 | 6.8 | 109 | 4.3 | 330 | 8.3 | 364 | 14.3 | T10 | G | 14 | 30.86 |
| CFPG2300 | 2 | 300 | 0.8 | 171 | 6.7 | 151 | 5.9 | 330 | 8.3 | 364 | 14.3 | T10 | G | 19.5 | 42.99 |
| CFPG2400 | 2 | 400 | 0.65 | 210 | 8.3 | 176 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | H | 26.5 | 58.42 |
| CFPG2500 | 2 | 500 | 0.55 | 241 | 9.5 | 171 | 6.7 | 330 | 8.3 | 365 | 14.4 | T10 | H | 31.5 | 69.45 |
| CFPG2600 | 2 | 600 | 0.5 | 302 | 11.9 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | H | 38 | 83.78 |
| CFPG2800 | 2 | 800 | 0.4 | 410 | 16.1 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | I | 53.5 | 117.95 |
| CFPG21000 | 2 | 1000 | 0.3 | 475 | 18.7 | 175 | 6.9 | 330 | 8.3 | 367 | 14.4 | T10 | I | 64 | 141.10 |
| CFPG21500 | 2 | 1500 | 0.22 | 400 | 15.7 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | J | 97 | 213.85 |
| CFPG22000 | 2 | 2000 | 0.2 | 490 | 19.3 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | K | 130 | 286.60 |
| CFPG23000 | 2 | 3000 | 0.13 | 710 | 28 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 | K | 198 | 436.52 |
| CFPG2200S | 2 | 200 | 0.9 | 206 | 8.1 | 103 | 4.1 | 355 | 14 | 390 | 15.4 | T10 | G | 15.5 | 34.17 |
| CFPG2250S | 2 | 250 | 0.8 | 206 | 8.1 | 124 | 4.9 | 355 | 14 | 390 | 15.4 | T10 | G | 19 | 41.89 |
| CFPG2300S | 2 | 300 | 0.75 | 206 | 8.1 | 145 | 5.7 | 355 | 14 | 390 | 15.4 | T10 | G | 21 | 46.30 |
| CFPG2350S | 2 | 350 | 0.7 | 206 | 8.1 | 124 | 4.9 | 471 | 18.5 | 506 | 19.9 | T10 | G | 24 | 52.91 |
| CFPG2400S | 2 | 400 | 0.6 | 206 | 8.1 | 145 | 5.7 | 471 | 18.5 | 506 | 19.9 | T10 | G | 27.5 | 60.63 |
| CFPG2500S | 2 | 500 | 0.5 | 206 | 8.1 | 166 | 6.5 | 471 | 18.5 | 506 | 19.9 | T10 | G | 32 | 70.55 |
| CFPG2600S | 2 | 600 | 0.45 | 206 | 8.1 | 145 | 5.7 | 646 | 25.4 | 681 | 26.8 | T10 | G | 43 | 94.80 |
| CFPG2800S | 2 | 800 | 0.4 | 210 | 8.3 | 191 | 7.5 | 646 | 25.4 | 681 | 26.8 | T10 | H | 60 | 132.28 |
| CFPG21000S | 2 | 1000 | 0.33 | 233 | 9.2 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 | H | 71 | 156.53 |
| CFPG21200S | 2 | 1200 | 0.28 | 275 | 10.8 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 | H | 87 | 191.80 |
| CFPG21500S | 2 | 1500 | 0.22 | 275 | 10.8 | 210 | 8.3 | 796 | 31.3 | 831 | 26.8 | T10 | H | 105 | 231.49 |
| CFPG22000S | 2 | 2000 | 0.2 | 399 | 15.7 | 210 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 150 | 330.69 |
| CFPG22500S | 2 | 2500 | 0.17 | 487 | 19.2 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 187 | 412.26 |
| CFPG23000S | 2 | 3000 | 0.13 | 576 | 22.7 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 | I | 223 | 491.63 |
Company Features
1. With core competitiveness of technology and quality, VELA Power Technology Co., Ltd. plays a leading role in the field of industry batteries .
2. With advanced technology applied in industrial battery , we take the lead in this industry.
3. Complying with the tenet of maintenance free battery helps VELA grow more in this market. Call now! Our factory always keep deep cycle battery as the tenet. Call now! Since founded, we insist the development tenet of industrial battery manufacturers . Call now!
